Recommended sitting position for this saddle:
:grayscale(false):quality(10):blur(20) "sqlabmtbmadeira2025byUrsGolling0188_grip_pressure_mapping")
:grayscale(false):quality(10):blur(20) "sqlabbestermountainbikesattel611ergowaveactive21ltdteamPT02")
Inspired by Passion, Driven by Performance
Built for long rides with comfort on every terrain
When team riders align with a brand’s vision and truly believe in the product, their passion becomes contagious. Their presence and success inspire us, while their experience in both competition and training helps us continuously improve and innovate.
:grayscale(false):quality(10):blur(20) "2023_07_27_SQlab 611 Sattel_Team Edt_C_Monica Gasbichler-17")
Step Saddle Shape
:grayscale(false):quality(10):blur(20) "2023_07_27_SQlab 611 Sattel_Team Edt_C_Monica Gasbichler-1")
Flat nose
:grayscale(false):quality(10):blur(20) "2023_07_27_SQlab 611 Sattel_Team Edt_C_Monica Gasbichler-15")
Saddle Dip
:grayscale(false):quality(10):blur(20) "sqlab.produkte.sattel.611.ergowave.active.2.1.sattelbreiten")
individual fit
Saddle width system
A perfectly tailored fit for the mountain biker is a prerequisite for maximum comfort, even off-road. Available widths: 13 / 14 / 15 / 16 cm
Find your fit
:grayscale(false):quality(10):blur(20) "sqlabmtbmadeira2025byUrsGolling0168")
Relief and Support
active-technology and ERGOWAVE®
The 611 MTB saddle features a stepped design that evenly transfers body weight to the sit bones. Its lower saddle nose and central dip alleviate pressure on sensitive areas for a balanced distribution. Additionally, the Active Technology enables lateral saddle movement during pedaling, helping to mobilize and relieve pressure on the spinal discs.
:grayscale(false):quality(10):blur(20) "sqlabbestermountainbikesattel611ergowaveactive21ltdteamPT04")
Perfect Support & Optimal Pressure Relief
Step Saddle Shape
With its wave-shaped design and raised rear, the saddle provides perfect support and even pressure distribution, offers relief and significantly improving power transfer to the pedals, especially during challenging uphills and fast descents.
| ARTICLE NUMBER | 57230-2074 |
|---|
| AREA OF USE | MTB, Trail & Down Country |
|---|
| WEIGHT(S) IN G | approx. 235 / 240 / 253 / 260 |
|---|
| LENGTH(S) IN MM | approx. 280 |
|---|
| SIZE(S) IN CM (EFFECTIVE SADDLE WIDTH) | 13 / 14 / 15 / 16 |
|---|
| ACTIVE TECHNOLOGY | Yes - Sport |
|---|
| MATERIAL RAILS | S-Tube (light metal alloy - hollow) |
|---|
| MATERIAL BASE | Glass Fibre reinforced Polyamide Compound (PA12 + GF) |
|---|
| MATERIAL PADDING | Superlight Foam |
|---|
| MATERIAL COVER | Impact Resistant Microfibre |
|---|
| HARDNESS IN SQ-SHORE | 55 |
|---|
| MAXIMUM LOAD IN KG | 100 |
|---|
| MAXIMUM TORQUE IN NM | 18 |
|---|
| E-BIKE READY | Yes |
|---|
| DIN/ASTM CATEGORIES | 4 |
|---|
| GENDER | Unisex, because of "Step saddle concept" and "Saddlewidth system" |
|---|
