INFINERGY® MATERIAL
Responsive, durable, made for the trail
Instead of traditional PU foam, the 611 uses BASF’s Infinergy®, known from running shoes. It’s highly resilient and offers excellent shock absorption – especially useful when riding off-road.
The cover isn’t fully bonded, but precisely fixed with strategically placed tapes – no glue involved. The foam and cover fuse directly, thanks to a manufacturing process developed in Germany by automotive supplier Oechsler.
:grayscale(false):quality(10):blur(20))
Saddle width system
Individual fit
No two riders are the same – which is why the 611 Infinergy® Clip-On comes in multiple widths. Matching the saddle to your sit bone distance helps distribute weight more effectively and improves overall comfort and control. A precise fit means fewer distractions and more focus on the ride.
ERGOWAVE®
Relief and support
The SQlab stepped saddle design promotes optimal pressure distribution by transferring weight from the sensitive perineal region to the sit bones. With a lower saddle nose that alleviates pressure on delicate areas and a central dip that supports healthy blood flow and nerve supply, this saddle enhances overall comfort.
:grayscale(false):quality(10):blur(20))
Defined sitting Position
Effiecent Power Transfer
With its wave-shaped design and raised rear, the saddle provides perfect support and even pressure distribution, offers relief and significantly improving power transfer to the pedals, especially during challenging uphills and fast descents.
:grayscale(false):quality(10):blur(20))
Active sitting position
The active technology enhances back support especially on long climbs. SQlab's active saddle technology adapts to pedaling motion, boosting comfort, mobilizing intervertebral discs, and reducing sit bone pressure—which can help to prevent lower back pain.
ARTICLE NUMBER | 57250-2096 |
---|
BAR CODE | 4062695008804, 4062695008811, 4062695008828, 4062695008835, 4062695008842 |
---|
SIZE(S) IN CM (EFFECTIVE SADDLE WIDTH) | 13 / 14 / 15 / 16 |
---|
AREA OF USE | Trail & Down Country |
---|
WEIGHT(S) IN G | 299/300/307/332/342 |
---|
LENGTH(S) IN MM | 287 |
---|
EFFECTIVE HEIGHT IN MM | 60 |
---|
ACTIVE TECHNOLOGY | Yes - Sport |
---|
MATERIAL RAILS | S-Tube (light stainless steel - hollow) |
---|
MATERIAL BASE | Glass Fibre reinforced Polyamide Compound (PA12 + GF) |
---|
MATERIAL PADDING | Infinergy® |
---|
MATERIAL COVER | Interlock Tapes |
---|
HARDNESS IN SQ-SHORE | 55 |
---|
RELIEF OF PERINEAL AREA IN % | 65 |
---|
MAXIMUM LOAD IN KG | 100 |
---|
MAXIMUM TORQUE IN NM | 18 |
---|
E-BIKE READY | Yes |
---|
DIN/ASTM CATEGORIES | 4 |
---|
GENDER | Unisex |
---|
